Bonded NdFeb Magnets

Rau qhov hloov pauv tau yooj yim dua rau sintered neodymium, xav txog kev siv cov hlau nplaum neodymium sib txuas rau koj daim ntawv thov. Bonded neodymium hmoov yog siv los tsim cov hlau nplaum no. Cov hmoov yog melted thiab tov nrog ib tug polymer. Cheebtsam yog ces nias los yog extruded los tsim cov khoom. Bonded Neodymium hlau nplaum tuaj yeem sib nqus rau hauv cov qauv nyuaj nrog ntau tus ncej. Txawm hais tias tsis muaj zog ntau dua li Sintered Neodymium hlau nplaum, Bonded neodymium hlau nplaum muab qhov yooj yim dua ntawm cov duab uas tuaj yeem ua tau. Lawv kuj sib zog dua li Samarium Cobalt, thiab muaj qhov kub thiab txias (coercivity). Txawm li cas los xij, lawv muaj txiaj ntsig zoo rau cov ntawv thov uas xav tau cov hlau nplaum me me lossis siv cov nplhaib radial.

1.Automotive Sensors: xws li ceev ceev, qhov chaw sensing, thiab anti-lock braking systems (ABS) vim lawv siab sib nqus zog thiab stability.

2.Electric Motors: suav nrog cov cuab yeej siv hluav taws xob, cov khoom siv hauv tsev, thiab kev siv tsheb, qhov twg lawv lub zog sib nqus sib nqus pab tau kom ua tiav cov qauv tsim thiab ua tau zoo.

3.Medical Devices: xws li MRI cov cav tov, cov cuab yeej kho hniav, thiab cov twj kho mob vim lawv cov hlau nplaum muaj zog thiab tsis kam mus demagnetization.

4.Consumer Electronics: suav nrog cov smartphones, laptops, thiab headphones, qhov twg lawv cov me me thiab siab sib nqus zog muaj txiaj ntsig.

5.Industrial Applications: xws li sib nqus couplings, sensors, thiab actuators

Lub sintered NdFeB hlau nplaum yog tsim los ntawmhmoov metallurgy txheej txheem. Ua ntej, cov smelted alloy yuav tsum tau hmoov thiab nias rau hauv lub compact nyob rau hauv ib tug sib nqus teb, thiab ces lub compact yog sintered nyob rau hauv inert roj los yog lub tshuab nqus tsev vacuum kom ua tiav densification.

Feem ntau, tsuas yog cov hlau nplaum tsis muaj peev xwm tuaj yeem tsim tau tom qab sintering, thiab tom qab ntawd nws tuaj yeem hloov mus rau hauv cov hlau nplaum ntawm ntau yam duab los ntawm kev siv tshuab (xws li hlau txiav, txiav, sib tsoo, thiab lwm yam).

Sintered NdFeB cov hlau nplaum ruaj khov yog siv dav hauv cov khoom siv hluav taws xob, hluav taws xob tshuab, khoom siv kho mob, cov khoom ua si, ntim khoom, tshuab kho vajtse, aerospace, thiab lwm yam. Cov khoom siv ntau dua yog cov hlau nplaum ruaj khov, cov neeg hais lus, cov khoom sib nqus sib nqus, lub khoos phis tawj disk, thiab cov cuab yeej siv magnetic resonance imaging.

Piv nrogBonded NdFeB hlau nplaum, sintered NdFeB hlau nplaummuaj cov nqi ua haujlwm siab, poob loj thaum ua tiav, thiab qhov tsis zoo ntawm qhov raug. Tab sis nws qhov txiaj ntsig kuj tseem pom tseeb. Tam sim no, (BH) max ntawm sintered NdFeB hlau nplaum tuaj yeem ncav cuag ntau dua 50M, thaum cov hlau nplaum sib txuas feem ntau qis dua 10M.

Everbeen Magnetyog tshwj xeeb hauv ntau yam hlau nplaum ruaj khov, thiab tau koom nrog hauv kev tsim khoom, kev tshawb fawb thiab kev muag khoom hauv cov hlau nplaum rau ntau tshaj 20 xyoo. Peb tsuas yog tsim sintered Neodymium hlau nplaum ntawm ntau qib, peb tuaj yeem kho cov hlau nplaum raws li cov neeg siv khoom tsim thiab thov. Dhau li ntawd, peb kuj muab Bonded NdFeB hlau nplaum, Alnico hlau nplaum, Samarium Cobalt (SmCo) hlau nplaum, Ferrite (ceramic) hlau nplaum, Flexible magnet (Rubber magnet) thiab sib nqus sib nqus.

Bonded neodymium-iron-boron (NdFeB) hlau nplaum yog cov hlau nplaum muaj zog uas siv rau ntau yam kev siv. Epoxy txheej feem ntau yog siv rau kev sib txuas NdFeB hlau nplaum; electroless nickel plating kuj yog siv los tiv thaiv corrosion. Isotropic bonded NdFeB cov ntaub ntawv tuaj yeem sib nqus hauv txhua qhov kev taw qhia, lossis nrog ntau tus ncej.

Cov khoom siv Bonded Nd-Fe-B yog isotropic, yog li nws tuaj yeem sib nqus los ntawm txhua qhov kev taw qhia, suav nrog ntau lub ntsiab lus. Vim hais tias cov khoom yog nyob rau hauv ib tug epoxy binder, nws yuav tsum machined nyob rau hauv lub zeb los yog tshuab dhos. Txawm li cas los xij, cov khoom siv yuav tsis txhawb cov xov, yog li qhov tsis tuaj yeem tapping. Cov khoom siv Bonded Nd-Fe-B feem ntau yog siv los txo qhov loj ntawm cov qauv tsim uas siv cov khoom siv hlau nplaum ceramic. Qhov loj me me tuaj yeem ua tiav vim tias cov khoom siv yog kwv yees li peb zaug muaj zog dua li cov khoom siv hlau nplaum ceramic. Tsis tas li ntawd, txij li cov khoom siv yog isotropic, nws tuaj yeem ua tau magnetized multi-polar, xws li NSNS qauv ntawm lub nplhaib sab nraud.

Kev txawj ntse thiab kev paub: 20+ xyoo dhau los hauv kev lag luam hlau nplaum, tag nrho peb cov kev muag khoom muaj 12+ xyoo kev txawj ntse thiab kev paub hauv ntau hom hlau nplaum ruaj khov.

Kev kho kom haum: feem ntau ntawm cov hlau nplaum muaj zog yog kho raws li kev kos duab thiab thov.

Cartons pob yog rau kev xa khoom huab cua, thiab peb yuav tuav cov thawv nrog ib rooj plaub lossis pallets rau kev xa khoom hiav txwv.

Cim npe nrov: ndfeb hlau nplaum, Tuam Tshoj bonded ndfeb hlau nplaum manufacturers, lwm tus neeg, Hoobkas
